S1447 12V 2.7kW Starter Motor Fits Toyota Fork Lift 5FD20
Price range: £136.68 through £162.48
The S1447 12V 2.7kW Starter Motor is a replacement starting unit from Sahibs Auto Electrics. Listed applications include selected Toyota Fork Lift 5FD20, Toyota Fork Lift 5FD23, Toyota Fork Lift 5FD25, Toyota Fork Lift 5FD28 models. Identification references include Lucas LRS01447, Denso 128000-0970, Delco Remy DRS0812. Its listed 12V 2.7kW rating provides an electrical matching point for your existing unit. Check the 11-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S1447 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.7 kW |
| Volt | 12 V |
| Plug | M10 |
| Rotation | Clockwise |
| Teeth | 11 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 8.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS1447 | Dyno Electrics |
| UD810304(DENSO)S | AS-PL |
| DRS0812 | DELCO |
| 128000-0970 | DENSO |
| 128000-0971 | DENSO |
| 128000-0972 | DENSO |
| 128000-0973 | DENSO |
| 128000-0974 | DENSO |
| 228000-3710 | DENSO |
| 228000-3711 | DENSO |
| 228080-3711 | DENSO |
| DSN2112 | DENSO |
| 28100-23660 | TOYOTA |
| 28100-23660-71 | TOYOTA |
| 28100-40290-71 | TOYOTA |
| 28100-40291-71 | TOYOTA |
| 2810040290 | TOYOTA |
| 2810040291 | TOYOTA |
| CST40127AS | CASCO |
| 8076 | CEVAM |
| 25-2373 | ELSTOCK |
| 3049479 | HYSTER |
| LRS01447 | LUCAS |
| LRS1447 | LUCAS |
| 190.534.112.050 | PSH |
| 190.534.112.058 | PSH |
| 190.534.112.260 | PSH |
| 190.534.112.310 | PSH |
| 190.534.112.415 | PSH |
| 20432721BN | REAL |
| 6040127 | SANDO |
| DENDSN2112 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| TOYOTA FORK LIFT | 5FD20 | 0ccm Diesel | 1Z | 1986 - 1994 | |||
| TOYOTA FORK LIFT | 5FD23 | 0ccm Diesel | 1Z | 1986 - 1994 | |||
| TOYOTA FORK LIFT | 5FD25 | 0ccm Diesel | 1Z | 1986 - 1994 | |||
| TOYOTA FORK LIFT | 5FD28 | 0ccm Diesel | 1Z | 1986 - 1994 | |||
| TOYOTA FORK LIFT | 5FD30 | 0ccm Diesel | 1Z | 1986 - 1994 | |||
| TOYOTA FORK LIFT | 6FD10 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD14 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD15 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD18 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD20 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD20 | 0ccm Diesel | 2Z | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD23 | 0ccm Diesel | 2Z | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD23 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD25 | 0ccm Diesel | 2Z | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD25 | 0ccm Diesel | 1DZ | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD28 | 0ccm Diesel | 2Z | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 6FD30 | 0ccm Diesel | 2Z | 1994 - 1998 | |||
| TOYOTA FORK LIFT | 7FD20 | 0ccm Diesel | 2Z | 1998 - | |||
| TOYOTA FORK LIFT | 7FD20 | 0ccm Diesel | 1DZ | 1998 - | |||
| TOYOTA FORK LIFT | 7FD23 | 0ccm Diesel | 1DZ | 1998 - | |||
| TOYOTA FORK LIFT | 7FD23 | 0ccm Diesel | 2Z | 1998 - | |||
| TOYOTA FORK LIFT | 7FD25 | 0ccm Diesel | 2Z | 1998 - | |||
| TOYOTA FORK LIFT | 7FD25 | 0ccm Diesel | 1DZ | 1998 - | |||
| TOYOTA FORK LIFT | 7FD28 | 0ccm Diesel | 1DZ | 1998 - | |||
| TOYOTA FORK LIFT | 7FD28 | 0ccm Diesel | 2Z | 1998 - | |||
| TOYOTA FORK LIFT | 7FD30 | 0ccm Diesel | 1DZ | 1998 - | |||
| TOYOTA FORK LIFT | 7FD30 | 0ccm Diesel | 2Z | 1998 - | |||
| TOYOTA FORK LIFT | 7FDJ35 | 0ccm Diesel | 2Z | 1998 - |
Description
S1447 Replacement Starter Motor
Choose a replacement by comparing the S1447 starter motor and its Lucas reference, LRS01447, with your existing unit. The listed electrical rating is 12V 2.7kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Toyota Fork Lift 5FD20 variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.7kW power: compare the listed rating with the original starter motor.
- 11-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M10 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Toyota Fork Lift 5FD20 – selected applications 1986–1994 (engine code 1Z).
- Toyota Fork Lift 5FD23 – selected applications 1986–1994 (engine code 1Z).
- Toyota Fork Lift 5FD25 – selected applications 1986–1994 (engine code 1Z).
- Toyota Fork Lift 5FD28 – selected applications 1986–1994 (engine code 1Z).
- Toyota Fork Lift 5FD30 – selected applications 1986–1994 (engine code 1Z).
- Toyota Fork Lift 6FD10 – selected applications 1994–1998 (engine code 1DZ).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S1447. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
128000-0970, 128000-0971, 128000-0972, 128000-0973, 128000-0974, 228000-3710, 228000-3711, 228080-3711, DSN2112, LRS01447, LRS1447, DRS0812
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S1447 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S1447 fit my Toyota Fork Lift 5FD20?
Toyota Fork Lift 5FD20 (1986–1994) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S1447 replace Lucas LRS01447?
Lucas LRS01447 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S1447?
The listed details include 12V, 2.7kW power, 11 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S1447 new or remanufactured?
Check the current product condition selection for S1447. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S1447?
Compare 12V compatibility, 2.7kW power, 11 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
