S1562 12V 3.0kW Starter Motor Fits New Holland L-60, New Holland L-65
Price range: £96.51 through £111.89
Sahibs S1562 is a replacement starter motor with a listed 12V 3.0kW rating. Listed applications include selected New Holland L-60, New Holland L-65, New Holland L-75, New Holland L-85 models. Identification references include Lucas LRS01562, Bosch 1230007, Prestolite S5014L. Its listed 12V 3.0kW rating provides an electrical matching point for your existing unit. Check the 9-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S1562 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 3 kW |
| Volt | 12 V |
| Plug | M10 |
| Rotation | Clockwise |
| Teeth | 9 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 8.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS1562 | Dyno Electrics |
| S0081 | AS-PL |
| 1230007 | BOSCH |
| 1230010 | BOSCH |
| 1230023 | BOSCH |
| 0001262007-R | BOSCH |
| 1262008 | BOSCH |
| 986018980 | BOSCH |
| 113182 | CARGO |
| F032113182 | CARGO |
| 5801441814 | CASE |
| 8EA012526-081 | HELLA |
| 500325145 | IVECO |
| 500338952 | IVECO |
| 504059251 | IVECO |
| 47783079 | NEW HOLLAND |
| 87470949 | NEW HOLLAND |
| S5014L | PRESTOLITE |
| PRSL092 | 3EFFE |
| STRL092 | 3EFFE |
| CGB-28980 | AINDE |
| 10440177 | ALANKO |
| 10441114 | ALANKO |
| AEY1562 | AUTOELECTRO |
| SBO153 | AUTOTEAM |
| CST10153AS | CASCO |
| CST10153GS | CASCO |
| CST10518GS | CASCO |
| 8039 | CEVAM |
| 619021092 | DRI |
| STR10201 | ELECTROLOG |
| STR1927 | ELECTROLOG |
| 25-3059 | ELSTOCK |
| 220550 | ERA |
| 104720 | FARCOM |
| SG0093 | GHIBAUDI |
| 3122835 | HENKEL PARTS |
| 3122836 | HENKEL PARTS |
| 3122837 | HENKEL PARTS |
| 3122839 | HENKEL PARTS |
| H5010333 | HOFFER |
| H5010333G | HOFFER |
| 10010153AV | ITAB AUTOMOTIVE |
| 10010153OV | ITAB AUTOMOTIVE |
| 254521 | KUHNER |
| 254521B | KUHNER |
| 254521I | KUHNER |
| LES0379 | LE PART |
| LRS01562 | LUCAS |
| LRS1562 | LUCAS |
| 5010333 | MEAT & DORIA |
| 330450 | MEC DIESEL |
| 590.530.093.011 | PSH |
| 590.530.093.012 | PSH |
| 590.530.093.090 | PSH |
| 590.530.093.091 | PSH |
| 590.530.093.280 | PSH |
| 590.530.093.311 | PSH |
| 590.530.093.313 | PSH |
| 20401351BN | REAL |
| 20401351OE | REAL |
| 20401815OE | REAL |
| 011-001-000643R | REMANTE |
| RNL1898 | RNL |
| 6010153 | SANDO |
| 6010518.1 | SANDO |
| S12BH0857 | SIDAT |
| S12BH0857A2 | SIDAT |
| MAV121530 | SIOM |
| STX210081 | STARDAX |
| TT15129 | TESLA |
| ST01150 | TMI |
| 18374N | WAI / TRANSPO |
| WG2045405 | WILMINK GROUP |
| STR22029 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| NEW HOLLAND | L-60 | 0ccm Diesel | 1996 - 1999 | ||||
| NEW HOLLAND | L-65 | 0ccm Diesel | 1996 - 1999 | ||||
| NEW HOLLAND | L-75 | 0ccm Diesel | 1996 - 1999 | ||||
| NEW HOLLAND | L-85 | 0ccm Diesel | Iveco 8045.25 | 1996 - 1999 | |||
| NEW HOLLAND | L-95 | 0ccm Diesel | Iveco 8045.25 | 1996 - 1999 | |||
| NEW HOLLAND | LM640 | 0ccm Diesel | 8045.05B.576 | ||||
| NEW HOLLAND | TL100 | 3908ccm Diesel | 8045.25K | 1998 - 2004 | |||
| NEW HOLLAND | TL70 | 3908ccm Diesel | 8045.06 | 1998 - 2004 | |||
| NEW HOLLAND | TL80 | 3908ccm Diesel | 8045.05 | 1998 - 2004 | |||
| NEW HOLLAND | TL90 | 3908ccm Diesel | 8045.25 | 1998 - 2004 |
Description
S1562 Replacement Starter Motor
Choose a replacement by comparing the S1562 starter motor and its Lucas reference, LRS01562, with your existing unit. The listed electrical rating is 12V 3.0kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected New Holland L-60 variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 3.0kW power: compare the listed rating with the original starter motor.
- 9-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M10 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- New Holland L-60 – selected applications 1996–1999.
- New Holland L-65 – selected applications 1996–1999.
- New Holland L-75 – selected applications 1996–1999.
- New Holland L-85 – selected applications 1996–1999 (engine code Iveco 8045.25).
- New Holland L-95 – selected applications 1996–1999 (engine code Iveco 8045.25).
- New Holland LM640 (engine code 8045.05B.576).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S1562. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1230007, 1230010, 1230023, 0001262007-R, 1262008, 986018980, LRS01562, LRS1562, S5014L
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S1562 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S1562 fit my New Holland L-60?
New Holland L-60 (1996–1999) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S1562 replace Lucas LRS01562?
Lucas LRS01562 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S1562?
The listed details include 12V, 3.0kW power, 9 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S1562 new or remanufactured?
Check the current product condition selection for S1562. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S1562?
Compare 12V compatibility, 3.0kW power, 9 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
