A1763 12V 80A Alternator Fits Alfa Romeo 155, Alfa Romeo 164
Price range: £109.57 through £144.49
Identify a replacement alternator using Sahibs A1763, listed at 12V 80A. Listed applications include selected Alfa Romeo 155, Alfa Romeo 164 models. Identification references include Lucas LRA01763, Bosch 123320023, Delco Remy DRA3534. Its listed 12V 80A rating provides an electrical matching point for your existing unit. Check the 7-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1763 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 80 A |
| Volt | 12 V |
| No. of Grooves | 7 qty |
| Pulley Diameter | 60 mm |
| Mounting holes | 2 qty |
| Position | -60° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.85 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1763 | Dyno Electrics |
| UD02230A | AS-PL |
| 123320023 | BOSCH |
| 123345004 | BOSCH |
| DRA3534 | DELCO |
| 60583572 | FIAT |
| 60611990 | FIAT |
| 8EL737011-001 | HELLA |
| 9.43E+11 | MAGNETI MARELLI |
| 9517182 | MAGNETON |
| ALTF249 | 3EFFE |
| PRAF249 | 3EFFE |
| ANM35754X | ANDEL |
| CAL10295 | CASCO |
| CAL10295AS | CASCO |
| CAL10295ES | CASCO |
| CAL10295GS | CASCO |
| CAL10295OS | CASCO |
| CAL10295RS | CASCO |
| 4575 | CEVAM |
| 56512 | EAI |
| ALT1527 | ELECTROLOG |
| 28-3561 | ELSTOCK |
| 209091 | ERA |
| 9090132 | FRIESEN |
| CA1061IR | HC PARTS |
| 301061RI | KUHNER |
| 11.1061 | LAUBER |
| 441208 | LOGISTIK |
| LRA01763 | LUCAS |
| LRA1763 | LUCAS |
| 105.506.080 | PSH |
| 105.506.080.460 | PSH |
| 105.506.080.945 | PSH |
| 20101592BN | REAL |
| 20101592RC | REAL |
| 310613 | RHIAG |
| 2010295 | SANDO |
| ALT122950 | SIOM |
| ALT3220 | SIOM |
| STX101342 | STARDAX |
| UNIT BOM 220-5374 | WAI / TRANSPO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| ALFA ROMEO | 155 | 1.9 (1929ccm) Diesel | AR33601/AR67501 | 167A3/167A3B | 1993 - 1997 | ||
| ALFA ROMEO | 155 | 2.5 (2498ccm) Diesel | VM07B/VM31B | 167A1A/167A1G | 1993 - 1997 | ||
| ALFA ROMEO | 164 | 2.5 (2498ccm) Diesel | VM08B/VM32B | 164K2A/164K2B | 1992 - 1997 |
Description
A1763 Replacement Alternator
For a A1763 alternator enquiry, use Lucas reference LRA01763 alongside the vehicle and original unit details. The listed electrical rating is 12V 80A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Alfa Romeo 155 1.9 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 80A output: compare the listed rating with the original alternator.
- 7-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Alfa Romeo 155 1.9 Diesel – selected applications 1993–1997 (engine code AR33601/AR67501).
- Alfa Romeo 164 2.5 Diesel – selected applications 1992–1997 (engine code VM08B/VM32B).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1763. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
123320023, 123345004, LRA01763, LRA1763, DRA3534
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1763 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1763 fit my Alfa Romeo 155?
Alfa Romeo 155 1.9 Diesel (1993–1997) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1763 replace Lucas LRA01763?
Lucas LRA01763 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1763?
The listed details include 12V, 80A output, 7 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1763 new or remanufactured?
Check the current product condition selection for A1763. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1763?
Compare 12V compatibility, 80A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
